EV-D222 Compact Electric Utility Vehicle
*Heavy-Duty 2-Passenger Workhorse*
1. Core Specifications
| Parameter | Specification | Key Feature |
|---|
| Dimensions | 3850 × 1550 × 1850 mm | Compact work platform |
| Passenger Capacity | 2 (Operator + Crew) | Industrial seating |
| Performance | 30 km/h • 80 km range | Full-shift operation |
| Gradeability | 30% slope | Job site capable |
| Maneuverability | 6.5m turning radius | Tight worksite turns |
| Ground Clearance | 145 mm | Rough terrain ready |
| Braking | ≤5m stopping distance | Dual-circuit drums |
| Weight | 930 kg | Reinforced chassis |
| Tires | 155/60-R13 (alloy rim) | Commercial tread |
2. Heavy-Duty Powertrain
| Component | Specification | Advantage |
|---|
| Motor | 4kW AC (48V standard) | 72V upgrade available |
| Controller | 48V, 400A | Precision control |
| Charging | 8-hour full charge | Overnight ready |
3. Industrial Chassis
| System | Configuration | Durability |
|---|
| Braking | 4-wheel drum | Wet condition safety |
| Suspension | MacPherson front + Solid axle | 1000kg payload |
| Steering | Heavy-duty rack & pinion | Low maintenance |
4. Work-Ready Features
| Feature | Specification | Benefit |
|---|
| Display | Industrial LCD panel | Real-time monitoring |
| Lighting | LED work lights | 24/7 visibility |
| Construction | 2mm steel frame | Impact resistant |
Why Choose EV-D222?
✔ 930kg Reinforced Frame - Withstands daily worksite abuse
✔ 72V Upgrade Option - For extreme terrain (30% grade)
✔ All-Weather Brakes - Reliable stopping in any condition
Perfect For:
Optional accessories include weather enclosures and tool mounts.
